GATE ECE 2025
GATE 2025 Previous Year
3 hDuration
100Total Marks
64Questions
10Sections
Instructions
General instructions for this test:
- Duration: 3 h. The timer starts as soon as you begin and cannot be paused.
- Total questions: 64 across 10 section(s); maximum marks: 100.
- You are allowed 1 attempt(s) at this test.
- Use the question palette on the right to navigate. Answered questions are highlighted in green; questions marked for review are highlighted in yellow.
- Each question's marking scheme (correct / wrong) is shown on the question card. Unanswered questions receive zero marks.
- Switching tabs, exiting full-screen, or attempting to copy text is monitored. Repeated tab-switching may auto-submit the test.
- Your answers autosave as you navigate. Click Submit Test when you are done. The test will be auto-submitted when the timer expires.
No exam-specific instructions were provided for this paper.
Paper Structure
Electromagnetics
Electromagnetics
Q1.
numerical
+2 / 0
A $50 \Omega$ lossless transmission line is terminated with a load $Z_L$ of $(50-j 75) \Omega$. If the average incident power on the line is 10 mW , then the average power delivered to the load (in mW , rounded off to one decimal place) is _________ .
Q2.
mcq single
+2 / 0.67
A square metal sheet of $4 \mathrm{~m} \times 4 \mathrm{~m}$ is placed on the $x-y$ plane as shown in the figure below.
If the surface charge density (in $\mu \mathrm{C} / \mathrm{m}^2$ ) on the sheet is $\rho_s(x, y)=4|y|$, then the total charge (in $\mu \mathrm{C}$, rounded off to the nearest integer) on the sheet is___________ .
Q3.
numerical
+2 / 0
Two resistors are connected in a circuit loop of area $5 \mathrm{~m}^2$, as shown in the figure below. The circuit loop is placed on the $x-y$ plane. When a time-varying magnetic flux, with flux-density $B(t)=0.5 t$ (in Tesla), is applied along the positive $z$-axis, the magnitude of current $I$ (in Amperes, rounded off to two decimal places) in the loop is__________ .
Q4.
mcq single
+2 / 0.67
An electric field of $0.01 \mathrm{~V} / \mathrm{m}$ is applied along the length of a copper wire of circular crosssection with diameter 1 mm . Copper has a conductivity of $5.8 \times 10^7 \mathrm{~S} / \mathrm{m}$. The current (in Amperes, rounded off to two decimal places) flowing through the wire is ________
Analog Circuits
Analog Circuits
Q1.
mcq multi
+1 / 0
Which of the following statements is/are TRUE with respect to an ideal opamp?
Q2.
mcq multi
+2 / 0
All the diodes in the circuit given below are ideal.
Which of the following plots is/are correct when $V_I$ (in Volts) is swept from $-M$ to $M$ ?
Q3.
numerical
+2 / 0
The diode in the circuit shown below is ideal. The input voltage (in Volts) is given by $V_1=10 \sin 100 \pi t$, where time $t$ is in seconds.
The time duration (in ms, rounded off to two decimal places) for which the diode is forward biased during one period of the input is ________.
Q4.
mcq multi
+1 / 0
Which of the following statements is/are TRUE with respect to ideal MOSFET-based DCcoupled single-stage amplifiers having finite load resistors?
Q5.
mcq single
+2 / 0.67
The identical MOSFETs $M_1$ and $M_2$ in the circuit given below are ideal and biased in the saturation region. $M_1$ and $M_2$ have a transconductance $g_m$ of 5 mS .
The input signals (in Volts) are:
$$ \begin{aligned} & V_1=2.5+0.01 \sin \omega t \\ & V_2=2.5-0.01 \sin \omega t \end{aligned} $$
The output signal $V_3$ (in Volts) is _ .
Q6.
numerical
+1 / 0
All the components in the bandpass filter given below are ideal. The lower -3 dB frequency of the filter is 1 MHz .
The upper -3 dB frequency (in MHz, rounded off to the nearest integer) is ___________ .
Q7.
mcq single
+1 / 0.33
The ideal BJT in the circuit given below is biased in the active region with a $\beta$ of 100 .
If $I_B$ is $10 \mu \mathrm{~A}$, then $V_{C E}$ (in Volts, rounded off to two decimal places) is ____________ .
Q8.
mcq single
+2 / 0.67
In the circuit shown, the identical transistors Q1 and Q2 are biased in the active region with $\beta=120$. The Zener diode is in the breakdown region with $V_Z=5 \mathrm{~V}$ and $I_Z=25 \mathrm{~mA}$. If $I_L=12 \mathrm{~mA}$ and $V_{E B 1}=V_{E B 2}=0.7 \mathrm{~V}$, then the values of $R_1$ and $R_2$ (in $\mathrm{k} \Omega$, rounded off to one decimal place) are ___________ , respectively.
Q9.
mcq single
+1 / 0.33
A simplified small-signal equivalent circuit of a BJT-based amplifier is given below. The small-signal voltage gain $V_o / V_s$ (in $\mathrm{V} / \mathrm{V}$ ) is_________.
Signals And Systems
Signals And Systems
Q1.
mcq single
+2 / 0.67
Consider a continuous-time finite-energy signal $f(t)$ whose Fourier transform vanishes outside the frequency interval $\left[-\omega_c, \omega_c\right]$, where $\omega_c$ is in rad/sec.
The signal $f(t)$ is uniformly sampled to obtain $y(t)=f(t) p(t)$. Here
$$ p(t)=\sum_{n=-\infty}^{\infty} \delta\left(t-\tau-n T_s\right) $$
with $\delta(t)$ being the Dirac impulse, $T_s>0$, and $\tau>0$. The sampled signal $y(t)$ is passed through an ideal lowpass filter $h(t)=\omega_c T_s \frac{\sin \left(\omega_c t\right)}{\pi \omega_c t}$ with cutoff frequency $\omega_c$ and passband gain $T_s$.
The output of the filter is given by $\qquad$ .
Q2.
mcq single
+1 / 0.33
Consider the discrete-time system below with input $x[n]$ and output $y[n]$. In the figure, $h_1[n]$ and $h_2[n]$ denote the impulse responses of LTI Subsystems 1 and 2, respectively. Also, $\delta[n]$ is the unit impulse, and $b>0$.
Assuming $h_2[n] \neq \delta[n]$, the overall system (denoted by the dashed box) is_________.
Q3.
mcq single
+1 / 0.33
Consider a continuous-time, real-valued signal $f(t)$ whose Fourier transform $F(\omega)=$$\mathop f\limits_{ - \infty }^\infty $$ f(t) \exp (-j \omega t) d t$ exists.
Which one of the following statements is always TRUE?
Q4.
mcq multi
+1 / 0
Let $x[n]$ be a discrete-time signal whose $z$-transform is $X(z)$.
Which of the following statements is/are TRUE?
Q5.
mcq multi
+2 / 0
Let $f(t)$ be a periodic signal with fundamental period $T_0>0$. Consider the signal $y(t)=f(\alpha t)$, where $\alpha>1$.
The Fourier series expansions of $f(t)$ and $y(t)$ are given by
$$ f(t)=\sum\limits_{k = - \infty }^\infty c_k e^{j \frac{2 \pi}{T_0} k T} \text { and } y(t)=\sum\limits_{k = - \infty }^\infty d_k e^{j \frac{2 \pi}{T_0} \alpha k T} . $$
Which of the following statements is/are TRUE?
Network Theory
Network Theory
Q1.
mcq single
+2 / 0.67
The $Z$-parameter matrix of a two port network relates the port voltages and port currents as follows:
$$ \left[\begin{array}{l} V_1 \\ V_2 \end{array}\right]=Z\left[\begin{array}{l} I_1 \\ I_2 \end{array}\right] $$
The Z-parameter matrix (with each entry in Ohms) of the network shown below is
___________.
Q2.
mcq single
+1 / 0.33
Consider a part of an electrical network as shown below. Some node voltages, and the current flowing through the $3 \Omega$ resistor are as indicated.
The voltage (in Volts) at node $X$ is __________ .
Q3.
mcq single
+1 / 0.33
Let $i_C, i_L$, and $i_R$ be the currents flowing through the capacitor, inductor, and resistor, respectively, in the circuit given below. The AC admittances are given in Siemens(S). Which one of the following is true?
Q4.
mcq single
+2 / 0.67
In the circuit below, $M_1$ is an ideal AC voltmeter and $M_2$ is an ideal AC ammeter. The source voltage (in Volts) is $v_s(t)=100 \cos (200 t)$.
What should be the value of the variable capacitor $C$ such that the RMS readings on $M_1$ and $M_2$ are 25 V and 5 A , respectively?
Engineering Mathematics
Engineering Mathematics
Q1.
mcq multi
+2 / 0
Which of the following statements involving contour integrals (evaluated counter-clockwise) on the unit circle $C$ in the complex plane is/are TRUE?
Q2.
mcq single
+1 / 0.33
A pot contains two red balls and two blue balls. Two balls are drawn from this pot randomly without replacement.
What is the probability that the two balls drawn have different colours?
Q3.
numerical
+2 / 0
Two fair dice (with faces labeled 1, 2, 3, 4, 5, and 6) are rolled. Let the random variable $X$ denote the sum of the outcomes obtained.
The expectation of $X$ is ___________ (rounded off to two decimal places).
Q4.
mcq single
+1 / 0.33
Consider the matrix $A$ below:
$$ A=\left[\begin{array}{llll} 2 & 3 & 4 & 5 \\ 0 & 6 & 7 & 8 \\ 0 & 0 & \alpha & \beta \\ 0 & 0 & 0 & \gamma \end{array}\right] $$
For which of the following combinations of $\alpha, \beta$ and $\gamma$, is the rank of $A$ at least three?
(i) $\alpha=0$ and $\beta=\gamma \neq 0$
(ii) $\alpha=\beta=\gamma=0$
(iii) $\beta=\gamma=0$ and $\alpha \neq 0$
(iv) $\alpha=\beta=\gamma \neq 0$
Q5.
numerical
+2 / 0
Consider the vectors
$$ a=\left[\begin{array}{l} 1 \\ 1 \end{array}\right], b=\left[\begin{array}{c} 0 \\ 3 \sqrt{2} \end{array}\right] $$
For real-valued scalar variable $x$, the value of
$$ \min _x\|a x-b\|_2 $$
is___________(rounded off to two decimal places).
$\|\cdot\|_2$ denotes the Euclidean norm, i.e., for $y=\left[\begin{array}{l}y_1 \\ y_2\end{array}\right],\|y\|_2=\sqrt{y_1^2+y_2^2}$.
Q6.
numerical
+1 / 0
The function $y(t)$ satisfies
$$ t^2 y^{\prime \prime}(t)-2 t y^{\prime}(t)+2 y(t)=0 $$
where $y^{\prime}(t)$ and $y^{\prime \prime}(t)$ denote the first and second derivatives of $y(t)$, respectively. Given $y^{\prime}(0)=1$ and $y^{\prime}(1)=-1$, the maximum value of $y(t)$ over $[0,1]$ is ___________ (rounded off to two decimal places).
Q7.
mcq single
+2 / 0.67
Consider a non-negative function $f(x)$ which is continuous and bounded over the interval $[2,8]$. Let $M$ and $m$ denote, respectively, the maximum and the minimum values of $f(x)$ over the interval.
Among the combinations of $\alpha$ and $\beta$ given below, choose the one(s) for which the inequality
$$ \beta \leq \int_2^8 f(x) d x \leq \alpha $$
is guaranteed to hold.
Q8.
mcq multi
+1 / 0
Consider the function $f: \mathbb{R} \rightarrow \mathbb{R}$ defined as
$$ f(x)=2 x^3-3 x^2-12 x+1 $$
Which of the following statements is/are correct?
(Here, $\mathbb{R}$ is the set of real numbers.)
Q9.
mcq single
+1 / 0.33
Consider the following series:
(i) $\sum\limits_{n=1}^{\infty} \frac{1}{\sqrt{n}}$
(ii) $ \sum\limits_{n=1}^{\infty} \frac{1}{n(n+1)}$
(iii) $\sum\limits_{n=1}^{\infty} \frac{1}{n!}$
Control Systems
Control Systems
Q1.
mcq single
+1 / 0.33
Consider the unity-negative-feedback system shown in Figure (i) below, where gain $K \geq 0$. The root locus of this system is shown in Figure (ii) below. For what value(s) of $K$ will the system in Figure (i) have a pole at $-1+j 1$ ?
Q2.
mcq single
+2 / 0.67
Consider a system represented by the block diagram shown below. Which of the following signal flow graphs represent(s) this system? Choose the correct option(s).
Q3.
mcq single
+2 / 0.67
Consider the polynomial $p(s)=s^5+7 s^4+3 s^3-33 s^2+2 s-40$. Let $(L, I, R)$ be defined as follows.
$L$ is the number of roots of $p(s)$ with negative real parts.
$I$ is the number of roots of $p(s)$ that are purely imaginary.
$R$ is the number of roots of $p(s)$ with positive real parts.
Which one of the following options is correct?
Q4.
mcq single
+2 / 0.67
Let $G(s)=\frac{1}{10 s^2}$ be the transfer function of a second-order system. A controller $M(s)$ is connected to the system $G(s)$ in the configuration shown below. Consider the following statements.
(i) There exists no controller of the form $M(s)=\frac{K_I}{s}$, where $K_I$ is a positive real number, such that the closed loop system is stable.
(ii) There exists at least one controller of the form $M(s)=K_P+s K_D$, where $K_P$ and $K_D$ are positive real numbers, such that the closed loop system is stable.
Which one of the following options is correct?
Q5.
mcq single
+2 / 0.67
Consider a system where $x_1(t), x_2(t)$, and $x_3(t)$ are three internal state signals and $u(t)$ is the input signal. The differential equations governing the system are given by
$$ \frac{d}{d t}\left[\begin{array}{l} x_1(t) \\ x_2(t) \\ x_3(t) \end{array}\right]=\left[\begin{array}{ccc} 2 & 0 & 0 \\ 0 & -2 & 0 \\ 0 & 0 & 0 \end{array}\right]\left[\begin{array}{l} x_1(t) \\ x_2(t) \\ x_3(t) \end{array}\right]+\left[\begin{array}{l} 1 \\ 1 \\ 1 \end{array}\right] u(t) $$
Which of the following statements is/are TRUE?
Q6.
mcq single
+1 / 0.33
The Nyquist plot of a system is given in the figure below. Let $\omega_{\mathrm{P}}, \omega_Q, \omega_R$, and $\omega_{\mathrm{S}}$ be the positive frequencies at the points $P, Q, R$, and $S$, respectively. Which one of the following statements is TRUE?
General Aptitude
General Aptitude
Q1.
mcq single
+2 / 0.67
Identify the option that has the most appropriate sequence such that a coherent paragraph is formed:
P. Over time, such adaptations lead to significant evolutionary changes with the potential to shape the development of new species.
Q. In natural world, organisms constantly adapt to their environments in response to challenges and opportunities.
R. This process of adaptation is driven by the principle of natural selection, where favorable traits increase an organism's chances of survival and reproduction.
S. As environments change, organisms that can adapt their behavior, structure and physiology to such changes are more likely to survive.
Q2.
mcq single
+1 / 0.33
Here are two analogous groups, Group-I and Group-II, that list words in their decreasing order of intensity. Identify the missing word in Group-II.
Group-I: Abuse $\rightarrow$ Insult $\rightarrow$ Ridicule
Group-II: __________$\rightarrow$ Praise $\rightarrow$ Appreciate
Q3.
mcq single
+1 / 0.33
Had I learnt acting as a child, I__________a famous film star.
Select the most appropriate option to complete the above sentence.
Q4.
mcq single
+1 / 0.33
The 12 musical notes are given as $C, C^{\#}, D, D^{\#}, E, F, F^{\#}, G, G^{\#}, A, A^{\#}$. Frequency of each note is $\sqrt[12]{2}$ times the frequency of the previous note. If the frequency of the note $C$ is 130.8 Hz , then the ratio of frequencies of notes $F^{\#}$ and $C$ is:
Q5.
mcq single
+1 / 0.33
The following figures show three curves generated using an iterative algorithm. The total length of the curve generated after 'Iteration $n$ ' is:
Note: The figures shown are representative.
Q6.
mcq single
+2 / 0.67
A stick of length one meter is broken at two locations at distances of $b_1$ and $b_2$ from the origin (0), as shown in the figure. Note that 0<b $b_2<1$. Which one of the following is NOT a necessary condition for forming a triangle using the three pieces?
$$ \text { Note: All lengths are in meter. The figure shown is representative. } $$
Q7.
mcq single
+2 / 0.67
The table lists the top 5 nations according to the number of gold medals won in a tournament; also included are the number of silver and the bronze medals won by them. Based only on the data provided in the table, which one of the following statements is INCORRECT?
$$ \begin{array}{|c|c|c|c|} \hline \text { Nation } & \text { Gold } & \text { Silver } & \text { Bronze } \\ \hline \text { USA } & 40 & 44 & 41 \\ \hline \text { Canada } & 39 & 27 & 24 \\ \hline \text { Japan } & 20 & 12 & 13 \\ \hline \text { Australia } & 17 & 19 & 16 \\ \hline \text { France } & 16 & 26 & 22 \\ \hline \end{array} $$
Q8.
mcq single
+2 / 0.67
An organization allows its employees to work independently on consultancy projects but charges an overhead on the consulting fee. The overhead is 20\% of the consulting fee, if the fee is up to . $5,00,000$. For higher fees, the overhead is . $1,00,000$ plus $10 \%$ of the amount by which the fee exceeds . 5,00,000. The government charges a Goods and Services Tax of $18 \%$ on the total amount (the consulting fee plus the overhead). An employee of the organization charges this entire amount, i.e., the consulting fee, overhead, and tax, to the client. If the client cannot pay more than . 10,00,000, what is the maximum consulting fee that the employee can charge?
Q9.
mcq single
+1 / 0.33
Which one of the following plots represents $f(x)=-\frac{|x|}{x}$, where $x$ is a non-zero real number?
Note: The figures shown are representative.
Electronic Devices And Vlsi
Electronic Devices And Vlsi
Q1.
mcq single
+2 / 0.67
The intrinsic carrier concentration of a semiconductor is $2.5 \times 10^{16} / \mathrm{m}^3$ at 300 K . If the electron and hole mobilities are $0.15 \mathrm{~m}^2 / \mathrm{Vs}$ and $0.05 \mathrm{~m}^2 / \mathrm{Vs}$, respectively, then the intrinsic resistivity of the semiconductor (in $\mathrm{k} \Omega . \mathrm{m}$ ) at 300 K is _________
(Charge of an electron $e=1.6 \times 10^{-19} \mathrm{C}$.)
Q2.
mcq single
+2 / 0.67
The electron mobility $\mu_n$ in a non-degenerate germanium semiconductor at 300 K is $0.38 \mathrm{~m}^2 / \mathrm{Vs}$.
The electron diffusivity $D_n$ at 300 K (in $\mathrm{cm}^2 / \mathrm{s}$, rounded off to the nearest integer) is ____________
(Consider the Boltzmann constant $k_B=1.38 \times 10^{-23} \mathrm{~J} / \mathrm{K}$ and the charge of an electron $e=1.6 \times 10^{-19} \mathrm{C}$.)
Q3.
mcq multi
+1 / 0
Which of the following can be used as an n-type dopant for silicon?
Select the correct option(s).
Q4.
numerical
+2 / 0
An ideal p-n junction germanium diode has a reverse saturation current of $10 \mu \mathrm{~A}$ at 300 K . The voltage (in Volts, rounded off to two decimal places) to be applied across the junction to get a forward bias current of 100 mA at 300 K is __________. (Consider the Boltzmann constant $k_B=1.38 \times 10^{-23} \mathrm{~J} / \mathrm{K}$ and the charge of an electron $e=1.6 \times 10^{-19} \mathrm{C}$.)
Digital Circuits
Digital Circuits
Q1.
mcq single
+1 / 0.33
A full adder and an XOR gate are used to design a digital circuit with inputs $X, Y$, and $Z$, and output $F$, as shown below. The input $Z$ is connected to the carry-in input of the full adder.
If the input $Z$ is set to logic ' 1 ', then the circuit functions as __________ with $X$ and $Y$ as inputs.
Q2.
mcq single
+2 / 0.67
A positive-edge-triggered sequential circuit is shown below. There are no timing violations in the circuit. Input $P 0$ is set to logic ' 0 ' and $P 1$ is set to logic ' 1 ' at all times. The timing diagram of the inputs SEL and $S$ are also shown below.
The sequence of output $Y$ from time $T_0$ to $T_3$ is $\qquad$ .
Q3.
numerical
+2 / 0
In the circuit shown below, the AND gate has a propagation delay of 1 ns . The edgetriggered flip-flops have a set-up time of 2 ns , a hold-time of 0 ns , and a clock-to-Q delay of 2 ns .
The maximum clock frequency (in MHz , rounded off to the nearest integer) such that there are no setup violations is___________ .
Q4.
numerical
+1 / 0
A 4-bit weighted-resistor DAC with inputs $b_3, b_2, b_1$, and $b_0$ (MSB to LSB) is designed using an ideal opamp, as shown below. The switches are closed when the corresponding input bits are logic ' 1 ' and open otherwise.
When the input $b_3 b_2 b_1 b_0$ changes from 1110 to 1101, the magnitude of the change in the output voltage $V_O$ (in mV , rounded off to the nearest integer) is ____________.
Q5.
mcq single
+2 / 0.67
A 10-bit analog-to-digital converter (ADC) has a sampling frequency of 1 MHz and a full scale voltage of 3.3 V .
For an input sinusoidal signal with frequency 500 kHz , the maximum SNR (in dB, rounded off to two decimal places) and the data rate (in Mbps) at the output of the ADC are
_________ , respectively.
Q6.
mcq single
+1 / 0.33
A 3-input majority logic gate has inputs $X, Y$ and $Z$. The output $F$ of the gate is logic ' 1 ' if two or more of the inputs are logic ' 1 '. The output $F$ is logic ' 0 ' if two or more of the inputs are logic '0'.
Which one of the following options is a Boolean expression of the output $F$ ?
Communications
Communications
Q1.
mcq single
+2 / 0.67
A source transmits symbol $S$ that takes values uniformly at random from the set $\{-2,0,2\}$. The receiver obtains $Y=S+N$, where $N$ is a zero-mean Gaussian random variable independent of $S$. The receiver uses the maximum likelihood decoder to estimate the transmitted symbol $S$.
Suppose the probability of symbol estimation error $P_e$ is expressed as follows:
$$ P_e=\alpha P(N>1), $$
where $P(N>1)$ denotes the probability that $N$ exceeds 1 .
What is the value of $\alpha$ ?
Q2.
numerical
+2 / 0
$X$ and $Y$ are Bernoulli random variables taking values in $\{0,1\}$. The joint probability mass function of the random variables is given by:
$$ \begin{aligned} & P(X=0, Y=0)=0.06 \\ & P(X=0, Y=1)=0.14 \\ & P(X=1, Y=0)=0.24 \\ & P(X=1, Y=1)=0.56 \end{aligned} $$
The mutual information $I(X ; Y)$ is ___________(rounded off to two decimal places).
Q3.
mcq multi
+2 / 0
The random variable $X$ takes values in $\{-1,0,1\}$ with probabilities $P(X=-1)=P(X=1)$ and $\alpha$ and $P(X=0)=1-2 \alpha$, where $0<\alpha<\frac{1}{2}$.
Let $g(\alpha)$ denote the entropy of $X$ (in bits), parameterized by $\alpha$. Which of the following statements is/are TRUE?
Q4.
mcq single
+1 / 0.33
Consider an additive white Gaussian noise (AWGN) channel with bandwidth $W$ and noise power spectral density $\frac{N_o}{2}$. Let $P_{a v}$ denote the average transmit power constraint. Which one of the following plots illustrates the dependence of the channel capacity $C$ on the bandwidth $W$ (keeping $P_{a v}$ and $N_0$ fixed)?
Q5.
numerical
+1 / 0
The generator matrix of a $(6,3)$ binary linear block code is given by
$$ G=\left[\begin{array}{llllll} 1 & 0 & 0 & 1 & 0 & 1 \\ 0 & 1 & 0 & 0 & 1 & 1 \\ 0 & 0 & 1 & 1 & 1 & 0 \end{array}\right] $$
The minimum Hamming distance $d_{\min }$ between codewords equals___________ (answer in integer).
Q6.
mcq single
+2 / 0.67
Consider a real-valued random process
$$ f(t)=\sum\limits_{n=1}^N a_n p(t-n T), $$
where $T>0$ and $N$ is a positive integer. Here, $p(t)=1$ for $t \in[0,0.5 T]$ and 0 otherwise. The coefficients $a_n$ are pairwise independent, zero-mean unit-variance random variables. Read the following statements about the random process and choose the correct option.
(i) The mean of the process $f(t)$ is independent of time $t$.
(ii) The autocorrelation function $E[f(t) f(t+\tau)]$ is independent of time $t$ for all $\tau$. (Here, $E[\cdot]$ is the expectation operation.)
Q7.
mcq multi
+1 / 0
Consider a message signal $m(t)$ which is bandlimited to $[-W, W]$, where $W$ is in Hz . Consider the following two modulation schemes for the message signal:
Double sideband-suppressed carrier (DSB-SC):
$$ f_{\mathrm{DSB}}(t)=A_c m(t) \cos \left(2 \pi f_c t\right) $$
Amplitude modulation (AM):
$$ f_{\mathrm{AM}}(t)=A_c(1+\mu m(t)) \cos \left(2 \pi f_c t\right) $$
Here, $A_c$ and $f_c$ are the amplitude and frequency (in Hz ) of the carrier, respectively. In the case of AM, $\mu$ denotes the modulation index.
Consider the following statements:
(i) An envelope detector can be used for demodulation in the DSB-SC scheme if $m(t)>0$ for all $t$.
(ii) An envelope detector can be used for demodulation in the AM scheme only if $m(t)>0$ for all $t$.
Which of the following options is/are correct?
Q8.
mcq single
+1 / 0.33
Consider a frequency-modulated (FM) signal
$$ f(t)=A_c \cos \left(2 \pi f_c t+3 \sin \left(2 \pi f_1 t\right)+4 \sin \left(6 \pi f_1 t\right)\right) $$
where $A_c$ and $f_c$ are, respectively, the amplitude and frequency (in Hz ) of the carrier waveform. The frequency $f_1$ is in Hz , and assume that $f_c>100 f_1$.
The peak frequency deviation of the FM signal in Hz is $\qquad$
